1 Channel 5V 30A Opto Isolated Relay Module

1 Channel 5V 30A Opto Isolated Relay Module

This is an easy-to-use 1-channel relay board that operates on 5V. It allows direct control of a 240V power appliance using microcontrollers or low-voltage circuits. It is ideal for switching high-power 240V appliances such as lights, fans, and motors at lower voltages. The board features a high-quality relay capable of handling up to 30A at 240V AC or 15A at 24V DC.

The module provides all three relay connections - Common (COM), Normally Open (NO), and Normally Closed (NC) - via a 3-pin screw terminal, making it easy to connect and disconnect loads. It also features power and relay status LEDs for quick debugging. The power input and relay control signals are accessible via header pins, enabling seamless interfacing with development boards using female-to-female jumper wires.

Features

• Supports switching of 240VAC/30A circuits safely
• Optocoupler isolation ensures stable and reliable operation
• Jumper-selectable high-level or low-level trigger input
• Power indicator (Green LED) and relay status indicator (Red LED)
• Fault-tolerant design: The relay does not switch due to control line faults or noise interference

Technical Specifications

Module Interface Specifications

Applications:

• Industrial automation
• Home and commercial appliance control
• Motor and pump switching
• Power management systems
• IoT and smart home projects

Packaging Details

• 1 x 1 Channel 5V 30A Opto Isolated Relay Module

Attention

Note: This item is non-returnable. If this item arrives damaged or is not functioning properly, please contact us to determine if further actions may be taken.
