ESP32 C6 WROOM Module 16MB PCB Antenna

ESP32 C6 WROOM Module 16MB PCB Antenna

SKU: WIR-00150

Brand: SparkFun, USA

Warranty: N/A

Model: N/A

৳ 970.08

Add to Wishlist

Category: ESP Development Board

Share:

Description of ESP32 C6 WROOM Module 16MB PCB Antenna

Overview


The ESP32-C6 WROOM Module is a highly integrated, low-power wireless microcontroller module that supports Wi-Fi 6 (2.4 GHz), Bluetooth 5 (LE), and IEEE 802.15.4 for Zigbee and Thread. It is based on a dual-core RISC-V processor architecture, featuring both high-performance (HP) and low-power (LP) cores, allowing dynamic power optimization in a variety of IoT applications.
This specific variant includes 16MB flash memory, offering extended storage for firmware, OTA updates, and complex applications

Key Feature


  • Dual-core 32-bit RISC-V processors (HP up to 160 MHz, LP up to 20 MHz)
  • Integrated Wi-Fi 6 (802.11ax), fully backward-compatible with b/g/n
  • Supports Bluetooth 5.3 LE, mesh networking, and advanced advertising
  • Integrated IEEE 802.15.4 radio for Zigbee 3.0 and Thread 1.3 protocols
  • Efficient OFDMA and MU-MIMO for high-density environments
  • 16MB onboard SPI Flash Memory
  • Built-in 12-bit ADC, temperature sensor, and multiple PWM channels
  • Internal coexistence mechanism for Wi-Fi and Bluetooth sharing the same antenna
  • RoHS/REACH and FCC/CE/SRRC certified for compliance
  • PCB antenna for space-saving design and robust connectivity

Technical Specifications


Parameter

Specification

Processor

ESP32-C6, 32-bit RISC-V, Single-Core (up to 160 MHz HP, 20 MHz LP)

ROM

320 KB

SRAM

512 KB HP SRAM, 16 KB LP SRAM

Flash Memory

16 MB SPI Flash

Wi-Fi

2.4 GHz Wi-Fi 6 (802.11ax), backward compatible with b/g/n

Wi-Fi Features

1T1R, OFDMA (UL/DL), MU-MIMO (DL), 2412–2484 MHz

Bluetooth

Bluetooth 5.3 LE, mesh support, up to 2 Mbps

BLE Features

Advertising extensions, LE power control, multi-set advertising

IEEE 802.15.4

Zigbee 3.0, Thread 1.3, OQPSK PHY, 250 Kbps in 2.4 GHz band

Interfaces

GPIO, SPI, I2C, I2S, UART, RMT, PWM, SDIO, MCPWM, GDMA, ADC, USB Serial/JTAG

ADC

12-bit resolution

Timers & Debug

System timer, general-purpose timers, watchdog timers, JTAG debug

Antenna

On-board PCB antenna

Crystal Oscillator

40 MHz

Certifications

FCC, CE-RED, SRRC, RoHS, REACH

 Documentation


 Applications


  • Smart Home Devices (Matter-compliant end-nodes, Zigbee, Thread)
  • Wireless Sensors & Gateways
  • Industrial IoT (IIoT) and asset monitoring
  • BLE Mesh Networks
  • Battery-powered Embedded Devices
  • Wi-Fi 6 Applications in Dense Environments
  • Multi-protocol IoT Devices requiring interoperability

Packaging Details


  • 1 × ESP32 C6 WROOM Module 16MB PCB Antenna
