The 1N5822 is a Schottky Barrier Rectifier Diode designed for low forward voltage drop and fast switching. With a maximum average forward current of 3A and peak reverse voltage of 40V, it is widely used in power supply designs, DC-DC converters, and protection circuits. Its compact DO-201AD package ensures ease of integration in through-hole PCB assemblies.
Parameter | Details | |||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Maximum Repetitive Peak Reverse Voltage (VRRM) | 40V | |||||||||||||||||||||||||||||
Maximum Average Forward Current (IO) | 3A | |||||||||||||||||||||||||||||
Peak Forward Surge Current (IFSM) | 80A | |||||||||||||||||||||||||||||
Maximum Forward Voltage Drop (VF) | 0.525V (at 3A) | |||||||||||||||||||||||||||||
Maximum Reverse Current (IR) | 1mA (at 40V) | |||||||||||||||||||||||||||||
Operating Junction Temperature (TJ) | -65°C to +150°C | |||||||||||||||||||||||||||||
Storage Temperature (Tstg) | -65°C to +150°C | |||||||||||||||||||||||||||||
Thermal Resistance Junction-to-Ambient (RθJA) | 50°C/W | |||||||||||||||||||||||||||||
Thermal Resistance Junction-to-Lead (RθJL) | 15°C/W | |||||||||||||||||||||||||||||
Package Type | DO-201AD Axial Leaded | |||||||||||||||||||||||||||||
Polarity | Cathode band marking | |||||||||||||||||||||||||||||
Approximate Weight | 1.2g |
