TTGO T Watch Wearable ESP32 Chip Touch Display Programmable in Bangladesh
TTGO T Watch Wearable ESP32 Chip Touch Display Programmable in Bangladesh

TTGO T Watch Wearable ESP32 Chip Touch Display Programmable

SKU: 250921005039

Brand: Made in China

Warranty: 3 Days

Model: N/A

৳ 7200.08

Add to Wishlist

Category: ESP Development Board

Share:

Description of TTGO T Watch Wearable ESP32 Chip Touch Display Programmable

The TTGO T Watch Wearable ESP32 Chip Touch Display Programmable is a powerful and versatile development smartwatch designed for IoT, embedded systems, and DIY wearable projects. Powered by the ESP32 dual-core MCU, it features Wi-Fi and Bluetooth connectivity, a capacitive touch display, built-in sensors, and flexible power management — making it ideal for prototyping and advanced IoT applications.


Key Features

  • Powered by ESP32 dual-core MCU with integrated Wi-Fi & Bluetooth.
  • 1.54-inch LCD capacitive touch display for smooth interaction.
  • Equipped with a BMA423 three-axis accelerometer and RTC clock module.
  • Supports lithium battery power with AXP202 power management system.
  • Programmable firmware upgrade via UART or OTA.

Specification

Category Parameter Details
Hardware Chipset ESP32 dual-core MCU with PMU power management
Flash Memory QSPI Flash 16MB
SRAM / PSRAM 520KB SRAM / 8MB PSRAM
Button Power key
USB to TTL CP2104
On-board Clock 40MHz Crystal Oscillator
Working Voltage 2.7V – 3.6V
Working Temperature -40°C ~ +85°C
Weight 58.5g
Display 1.54-inch LCD capacitive touch screen
Sensor BMA423 three-axis accelerometer, step counting, activity tracking, gesture recognition
RTC Clock PCF8563
Power Supply Power Input Micro USB (5V / 1A)
Charging Current Programmable and self-adjustable
Battery Lithium battery (not included)
Wi-Fi Standard FCC / CE-RED / IC / TELEC / KCC / SRRC / NCC (ESP32 chip)
Protocol 802.11 b/g/n (up to 150Mbps), A-MPDU & A-MSDU, 0.4μs guard interval
Frequency Range 2.4GHz ~ 2.5GHz (2400M ~ 2483.5M)
Transmit Power 22 dBm
Communication Distance Up to 300 meters
Bluetooth Protocol Bluetooth v4.2 BR/EDR and BLE
Radio Frequency -97 dBm sensitivity NZIF receiver, Class 1/2/3 emitter with AFH
Audio Codec Supports CVSD & SBC
Software Wi-Fi Mode Station / SoftAP / SoftAP+Station / P2P
Security Mechanism WPA / WPA2 / WPA2-Enterprise / WPS
Encryption Type AES / RSA / ECC / SHA
Firmware Upgrade UART download / OTA via network or host
Software Development Cloud server & SDK for firmware development
Networking Protocol IPv4, IPv6, SSL, TCP, UDP, HTTP, FTP, MQTT
User Configuration AT Command Set, Cloud, Android/iOS App
Operating System FreeRTOS

T-Watch Function Configuration

Parameter Details
Main Chip ESP32
LCD Capacitive Touch Screen 1.54 inch, ST7789
PMU Power Management AXP202
Touch Screen Chip FT6236U
Triaxial Accelerometer BMA423
Battery Type Lithium Battery
RTC Clock Module PCF8563
Vibration Motor Yes
Speaker Built-in
Infrared Signal Sensor Supported
PDM Microphone Included

ESP-32 Master Specifications

Parameter Details
Flash 16MB
P SRAM 8MB
Memory 520KiB SRAM
Wireless Connection Wi-Fi 802.11b/g/n
Bluetooth V4.2 BR/EDR and BLE
Charging Method Micro USB 5V
Working Voltage 3.3V
CPU Xtensa dual-core 32-bit LX6 microprocessor, operating frequency 240MHz, up to 600 DMIPS ultra-low power coprocessor

Applications

  • IoT Development and Prototyping
  • DIY Smartwatch and Wearable Projects
  • Wireless Sensor Networks
  • Educational and Research Applications

Package Contents

  • 1 × TTGO T Watch Wearable ESP32 Development Board
  • 1 × USB Cable
  • 1 × Quick Start Manual
