Digital Clamp Meter UNI-T UT203+

Digital Clamp Meter UNI-T UT203+

SKU: TOL-00150

Warranty: N/A

Model: N/A

৳ 4650.0

Add to Wishlist

Category: Measurement

Share:

Description of Digital Clamp Meter UNI-T UT203+

UT203+ digital clamp meter is designed according to EN61010-2010 CAT II 600V/CAT III 300V, featuring overload protection, high reliability, high safety and high accuracy.UNI-T UT203+ is a True RMS clamp meter which measures AC/DC voltage, AC/DC current, resistance, capacitance, frequency, duty ratio, continuity, and also may be used for diodes testing.



Features of UT203+ Digital Clamp Meter:-

  • Large screen and display digits
  • 60mF large capacitance measurement
  • Neutral/live wire test
  • Ideal for Industrial electricity, Residential electricity, Air conditioning, Automobile etc.
  • Functions:
    • AC/DC current;
    • AC/DC voltage;
    • resistance;
    • capacitance;
    • frequency;
    • duty ratio;
    • continuity test;
    • diode test.
  • True RMS measurement.
  • Audio visual NCV detection.
  • Large LCD with backlight.
  • Full-featured false detection protection for up to 600 V energy surges; overvoltage and overcurrent alarm functions.
  • The power consumption without backlight is about 1.8 mA. The circuit has an automatic power saving function. The consumption in sleep state is <11 μA, which extends the battery life to 400 hours.
  • Low battery indication.
  • Automatic power of after 15 of no-operation (function can be turned off).
  • Data hold function.
  • Max/Min mode.
  • REL measurements.



Specification:-



  • Brand: UNI-T
  • Model: 203+
  • Material: ABS
  • Safety Rating: CAT II 600V, CAT III 300V
  • Display Count: Max. 4000
  • Jaw Opening: 28mm
  • Auto off: 15 minutes
  • Range: Auto
  • AC Current Range: 40.00A/400.0A
  • AC Current Resolution: 0.01A/0.1A
  • DC Current Range: 40.00A/400.0A
  • DC Current Resolution: 0.01A/0.1A
  • AC Voltage Range: 4.000V/40.00V/400.0V/600V
  • AC Voltage Resolution: 0.001V/0.01V/0.1V/1V
  • AC Voltage Frequency: 10Hz~60kHz
  • AC Voltage Frequency Resolution: 0.01Hz~0.01kHz
  • DC Voltage Range: 400.0mV/4.000V/40.00V/400.0V/600V
  • DC Voltage Resolution: 0.1mV/0.001V/0.01V/0.1V/1V
  • Resistance Range: 400.0Ω/4.000kΩ/40.00kΩ/400.0kΩ/4.000MΩ/40.00MΩ
  • Resistance Resolution: 0.1Ω/0.001kΩ/0.01kΩ/0.1kΩ/0.001MΩ/0.01MΩ
  • Capacitance Range: 40.00nF/400.0nF/4.000uF/40.00uF/400.0uF/4.000mF/40.00mF
  • Capacitance Resolution: 0.01nF/0.1nF/0.001uF/0.01uF/0.1uF/0.001mF/0.01mF
  • Frequency Range: 10Hz~10MHz
  • Frequency Resolution: 0.01Hz~0.01MHz
  • Duty Cycle Range: 0.1%~99%
  • Duty Cycle Resolution: 0.1%
  • Continuity Range: 400.0Ω
  • Continuity Resolution: 0.1Ω
  • Diode Range: 4.000V
  • Diode Resolution: 0.001V
  • Operating Temperature: 0~30℃ (humidity ≤ 80%RH), 30~40℃ (humidity ≤ 75%RH), 40~50℃ (humidity ≤ 45%RH)
  • Storage Temperature & Humidity: -20~60℃, ≤ 80%RH
  • Altitude: 2,000 meters
  • Power Supply: 2 * 1.5V AAA battery (NOT included)
  • Item Size: 215 * 63.5 * 36mm / 8.46 * 2.5 * 1.41in
  • Item Weight: 268g / 9.45oz
  • Package Weight: 359g / 12.66oz
  • Package Size: 23.5 * 9.2 * 5.3cm / 9.25 * 3.62 * 2.09in



Package List:

  • 1 * UNI-T UT203 Digital Clamp Multimeter
  • 1 * Test Lead
  • 1 * Carrying Bag
  • 1 * English Manual



Documents:-



Check Specification Tab to know more.

User Manual Click Here
