IRF9520 P Channel Power MOSFET in Bangladesh
IRF9520 P Channel Power MOSFET in Bangladesh

IRF9520 P Channel Power MOSFET

SKU: 251210005123

Brand: Made in China

Warranty: 3 Days

৳ 70.04

Add to Wishlist

Category: MOSFET

Share:

Description of IRF9520 P Channel Power MOSFET

The IRF9520 is a third-generation P-Channel Power MOSFET from Vishay Siliconix. It is designed to offer an excellent combination of fast switching characteristics, a ruggedized device design, low on-resistance, and cost-effectiveness - making it well-suited for a variety of commercial and industrial power applications. Packaged in the TO-220AB format, this MOSFET is universally preferred for commercial and industrial applications that require power dissipation levels of up to approximately 50 W.



Features

The IRF9520 boasts several key features that enhance its performance and reliability in power management circuits:

  • P-Channel MOSFET configuration
  • Dynamic “dv/dt” rating
  • Repetitive avalanche rated
  • Fast switching performance – improves efficiency in high-frequency circuits
  • Ease of paralleling
  • Simple drive requirements
  • 175 °C operating temperature
  • Low on-resistance – reduces power loss and heat generation.



Technical Specifications

  • Part Number: IRF9520
  • Type: P-Channel Power MOSFET
  • Drain-Source Voltage (VDS): -100 V
  • Continuous Drain Current (ID): -6.8 A @ 25 °C
  • Continuous Drain Current (ID): -4.8 A @ 100 °C
  • Gate-source threshold voltage (VGS(th)): -2.0 V to -4.0 V
  • Package Type: TO-220AB
  • Maximum power dissipation: 60W
  • Minimum working temperature: -55 °C
  • Maximum working temperature: +175 °C
  • Total Gate Charge: 18 nC



Pinout Diagram

The TO-220AB package consists of three standard leads -

  • Pin 1: Gate (G)
  • Pin 2: Drain (D)
  • Pin 3: Source (S)

Image link



Application

The IRF9520 is suitable for a wide range of switching applications in the commercial and industrial sectors. Due to its P-Channel nature, low on-resistance, and high temperature rating, typical applications include:

  • Power supplies and inverters
  • Motor control
  • Battery-operated systems
  • Switching regulators
  • DC-DC converters



Documents / Resources

You can access the necessary resource files and related documents directly from Vishay:



Package Includes

  • 1 × IRF9520 P-Channel Power MOSFET
