The Sanwa CD800A Digital Multimeter is designed for accurate measurement of electrical parameters commonly encountered in testing and troubleshooting work. It supports DC and AC voltage and current measurement along with resistance, capacitance, frequency, and duty cycle, allowing a wide range of electrical and electronic checks using a single device. The 4000-count LCD display ensures clear numerical readings, while the stable sampling rate provides consistent measurement results during use.
Continuity testing with an audible buzzer and diode test functionality make it suitable for circuit inspection and component testing. High input impedance helps maintain measurement accuracy, especially in voltage testing applications. The meter operates on standard batteries, offers long operating time, and includes fuse protection for safe operation. Its layout and control design allow straightforward handling during routine electrical testing, repair work, and laboratory use.
| Function | Measuring Range | Best Accuracy | Resolution | Input Impedance |
|---|---|---|---|---|
| DC Voltage (DCV) | 400m / 4 / 40 / 400 / 600 V | ±(0.7% + 3) | 0.1 mV | 10MΩ – 100MΩ |
| AC Voltage (ACV) | 4 / 40 / 400 / 600 V | ±(1.6% + 5) | 0.001 V | 10MΩ – 11MΩ |
| DC Current (DCA) | 40 mA / 400 mA | ±(2.2% + 5) | 0.01 mA | — |
| AC Current (ACA) | 40 mA / 400 mA | ±(2.8% + 5) | 0.01 mA | — |
| Resistance | 400 / 4k / 40k / 400k / 4M / 40M Ω | ±(1.2% + 5) | 0.1 Ω | — |
| Capacitance | 50n / 500n / 5µ / 50µ / 100µF | ±(5% + 10) | 0.01 nF | — |
| Frequency | 5 Hz – 100 kHz | ±(0.5% + 3) | — | — |
| Duty Cycle | 20% – 80% | ±(0.5% + 5) | — | — |
| Continuity | Buzzer at 10Ω–120Ω | — | — | Open voltage ≈ 0.4 V |
| Diode Test | — | — | — | Open voltage ≈ 1.5 V |
| Parameter | Specification |
|---|---|
| Display | 4000-count numeric LCD |
| Sampling Rate | 3 times per second |
| Bandwidth | 40 Hz – 400 Hz |
| Fuse | 0.5A / 250V, 1.5kA, Φ5×20 ceramic |
| Power Supply | R6P (1.5V) × 2 batteries |
| Battery Life | Approx. 500 hours (DCV range, manganese battery) |
| Dimensions | H176 × W104 × D46 mm |
| Weight | Approx. 340 g |
| Test Lead Length | Approx. 0.7 m |
| Pin Tip Length | 19 mm |
Before using this digital meter, please read this instruction manual carefully and thoroughly. This manual explains how to use the product safely and correctly. Keep it with the product for future reference whenever necessary.
Instructions listed under the heading "WARNING" must be strictly followed to prevent accidental burns or electrical shock.
The following symbols may appear on the multimeter, in this manual, or on related accessories. Understanding these symbols is important for safe and correct operation.
| Symbol | Description | Explanation |
|---|---|---|
| Caution / Warning | Indicates important safety information. Failure to follow instructions may result in damage, injury, or incorrect measurement. | |
| Dangerous Voltage | Warns of the presence of hazardous voltage that may cause electric shock. Avoid direct contact. | |
| ⎓ | DC (Direct Current) | Indicates direct current measurement or DC voltage input. |
| ~ | AC (Alternating Current) | Indicates alternating current measurement or AC voltage input. |
| Ω | Resistance | Symbol for resistance measurement in ohms. |
| Continuity | Indicates continuity test mode with audible buzzer. | |
| ➤ ◄ | Diode Test | Indicates diode test mode. |
| ⏚ | Ground | Indicates grounding or earth connection reference. |
| ⧈ | Double Insulation | Device is protected by double or reinforced insulation; no earth connection required. |
| Low Battery | Indicates the battery voltage is low and needs replacement for accurate readings. |
Start-Up Inspection
No display may suggest that a battery be exhausted.
Notes: Readings can be unstable if the leads are open. Accuracy is specified for sine-wave signals in the 40–400 Hz range.
Note: Do not apply voltage to the terminals during resistance measurement. Shield the test object if noise may affect the reading.
Note: The HOLD function does not operate in frequency mode.
Important: Never apply voltage directly to the current terminals.
TechShopBD offers up to one year of warranty and replacement support for its products, depending on the supplier(s) and product(s). The specific warranty duration for each product can be found on the respective product page. To be eligible for warranty and replacement support, customers must agree to our terms and conditions.
Note: This item is non-returnable. If this item arrives damaged or is not functioning properly, please don’t hesitate to contact us to determine if further action is required.
Our engineers are available to assist you. If you have any queries, please leave a comment below or call 09678110110 from 09:00 am to 06:00 pm (7 days a week). You can also reach us via WhatsApp or Facebook Inbox
|
Function |
Measuring Range |
Resolution |
Input Impedance |
|
DC Volt |
400m/4/40/400/600V |
0.1mv |
DC:10M-100MΩ AC:10M-11MΩ |
|
AC Volt |
4/40/400/600V |
0.001v |
|
|
DC Ampere |
40m/400mA |
0.01mA |
|
|
AC Ampere |
40m/400mA |
0.01mA |
|
|
Resistance |
400/4K/40K/400K/4M/40MΩ |
0.1Ω |
|
|
Capacitance |
50n/500n/5μ/50μ/100μF |
0.01nF |
|
|
Frequency |
5HZ-100KHZ |
||
|
Duty Cycle |
20%-80% |
||
|
Continuity |
Buzzer sounds at between 10Ω and120Ω. Open Voltage:Approx.0.4V |
||
|
Diode Test |
Open voltage: Approx. 1.5V |
||
|
Bandwidth |
40-400HZ (sine) |
||
|
Size/Weight |
H176*W104*D46mm/340g |
||
